KDP Bleed vs. No Bleed: When to Use 0.125” Margins for Non-Fiction Interiors (2026 Manual)

1. Bleed vs. No Bleed: The Physical Printing and Trimming Mechanics

Answer Capsule: KDP bleed vs no bleed interior refers to whether artwork extends past the final trim line. No-bleed interiors print only within the finished page size, leaving white margins. Bleed interiors print 0.125" (3.2 mm) beyond the trim edge on top, bottom, and outer sides, so any blade shift during industrial trimming still cuts through solid ink instead of exposing unprinted white paper.

That 0.125" figure is not a suggestion. It is a mechanical tolerance engineered around the physical reality of how books are actually cut. Understanding the machinery behind that number separates a designer who guesses from a production specialist who calculates.

The Industrial Rotary Trimmer: Where Books Actually Get Cut

Books are not trimmed one at a time with a craft knife. After folding and binding, printed signatures arrive at a three-knife rotary trimmer or a guillotine cutter stacked in lifts — sometimes 8, 12, or even 16 copies thick depending on page count and stock weight. The hydraulic clamp descends with 1,500 to 3,000 PSI of pressure, and three blades shear simultaneously: head, tail, and fore-edge. A single pass removes the rough folded edges and delivers a "clean" book block.

Here is the part most authors never see. Paper is not rigid. It is a compressible, fibrous mat. When the clamp bites down on a 400-page lift of 60# cream offset, the stack compresses, and individual sheets creep outward toward the open edge. The blade does not strike a perfectly static target. The paper moves. Vibration from the trimmer's motor, air trapped between sheets, and inconsistent clamp pressure across the lift all conspire to shift the cut line.

Now do the arithmetic. If your interior is built as no-bleed and your trim line sits exactly at the edge of a full-page photograph, a 1/16" outward drift leaves a 1.6 mm strip of bare paper along the fore-edge. A 1/16" inward drift slices 1.6 mm off your image. Multiply that across a 5,000-copy print run, and you have thousands of books with a white sliver running down the edge of every photo. It looks like a manufacturing defect because it is one — and the printer will bill you for it or reject the file at preflight.

Why Bleed Solves the Problem Mathematically

Bleed is a buffer zone of printed ink that lives entirely outside the finished page. For a KDP 6" × 9" trim size, a bleed interior is built at 6.125" × 9.25" — extending 0.125" on the top, bottom, and outer edge. The inner (gutter) edge does not receive bleed because it gets bound, not cut.

Read that last line again. The 0.125" bleed exists specifically to absorb a ±1/16" drift in both directions. If the blade lands 1.6 mm long, it cuts through ink. If it lands 1.6 mm short, it cuts through ink. The reader never sees the seam. The photograph bleeds cleanly off the page edge exactly as intended.

When No Bleed Is the Correct Choice

No-bleed is not a lesser option. For the majority of trade nonfiction, it is the correct engineering decision. If every page in your interior consists of a text block surrounded by clean white margins, there is nothing to bleed. A paragraph of body copy that ends 0.75" from the fore-edge has no ink near the blade. A 1/16" trim drift is invisible because the cut lands in empty paper.

Choose no-bleed for:

• Standard nonfiction and business books — running text, chapter openers, occasional line diagrams
• Memoirs and narrative nonfiction — prose-only interiors
• Novels — text blocks with drop caps and scene breaks
• Academic textbooks — text-heavy pages with inline figures that sit well inside the margins
• Any interior where ink never touches the trim edge

No-bleed also carries a practical advantage: your page count math stays simpler, and you avoid the file-size bloat of a 6.125" × 9.25" canvas. For a 320-page novel, no-bleed is the default and the right answer.

When Bleed Is Mandatory

The moment ink is designed to reach the edge of the page, bleed stops being optional. There is no middle ground. Either the artwork extends 0.125" past trim, or it will show a white sliver when the blade drifts. KDP's preflight will reject a file with edge-to-edge art and no bleed in most cases, and even if it passes, the printed result is a gamble.

Choose bleed for:

• Photo books and coffee-table books — full-bleed images across spreads
• Cookbooks — food photography that runs to the page edge
• Workbooks and journals — colored edge tabs, ruled lines that reach the margin, colored sidebars
• Dark chapter divider spreads — a full black or colored page separating sections
• Diagrams and infographics — technical illustrations that extend to the trim
• Full-page illustrations — children's books, graphic novels, art monographs

The Cost of Getting It Wrong

Mismatched bleed settings are one of the most common KDP rejection causes, and the failure modes are asymmetric.

Notice the fourth row. Forcing bleed on a text-only interior is not wrong — it is simply unnecessary. The reverse is what kills a print run. Edge art without bleed is a production defect waiting to happen across hundreds or thousands of copies.

The mechanical logic is unforgiving. A rotary trimmer cuts a stack, not a page. Paper shifts. Blades drift. The 0.125" bleed is the calculated cushion that turns an unpredictable cut into a predictable result. Set your interior canvas to 6.125" × 9.25" when any ink reaches the edge, keep every face and text block 0.25" inside the trim, and the trimmer's tolerance stops being your problem.

2. The 2026 Master Trim & Bleed Dimensions Table (All Formats)

Get this table wrong and nothing downstream saves you. Not your typography. Not your cover. Not your ISBN metadata. A single misplaced decimal in the bleed box produces a 0.125" white sliver along the head of every left-hand page, and KDP's automated print check will flag it before a human ever touches the file. Printers do not negotiate. They reproduce exactly what your PDF describes.

So here is the reference sheet. Six trim sizes. Six columns. Every number verified against current KDP paperback interior specifications, converted to both inches and millimeters, and broken out by edge so you can see precisely where the extra 0.125" goes and — more importantly — where it does not.

The Master Dimensions Table

Read the table left to right and the pattern is mechanical, not arbitrary. Every bleed width is exactly 0.125" wider than its trim width. Every bleed height is exactly 0.250" taller than its trim height. The inside column is 0.000" for every single format, and that zero is not a rounding artifact — it is a structural law of perfect binding, and we will prove it below.

The Three Formulas Behind Every Cell

You do not need to memorize the table. You need to memorize three lines of arithmetic. Every bleed dimension in the grid above is derived from them.

Run the math on the 6" × 9" trade paperback, the single most common KDP interior format in circulation:

• Width: 6.000" + 0.125" = 6.125"
• Height: 9.000" + 0.250" = 9.250"
• Total canvas area: 6.125" × 9.250" = 56.656 square inches
• Trim area: 6.000" × 9.000" = 54.000 square inches
• Bleed waste: 56.656 − 54.000 = 2.656 square inches per page

On a 320-page novel, that is 2.656 × 320 = 849.9 square inches of printed area that gets sliced off by the guillotine. Roughly 5.9 square feet of ink and paper sacrificed so that a full-bleed chapter opener does not show a hairline of unprinted stock. That is the cost of the effect. Budget it.

Why the Inside Edge Never Gets Bleed

This is the part that trips up first-time designers, and it deserves a physical explanation rather than a rule handed down from on high.

Print sheets for a paperback are not printed one page at a time. They are imposed — 16 or 32 pages arranged on a large press sheet, front and back. That sheet is folded, collated with its siblings into a book block, and then the whole stack is bound along one edge. The spine edge. The inside edge of every page.

Now follow the paper. After binding, the book block is placed in a three-knife trimmer. Three blades. Not four. One blade shaves the head (top), one shaves the tail (bottom), and one shaves the fore-edge (the outside edge opposite the spine). The spine edge is never cut, because cutting it would sever the binding glue and the folded signatures that hold the book together.

So the three cut edges need bleed. The uncut edge does not. If you add 0.125" of bleed on the inside edge, you are not extending artwork past a trim line — there is no trim line there. You are simply shifting your trim box 0.125" off-center on the canvas, and the printer will either reject the file or, worse, print it and produce pages whose text block drifts visibly toward the gutter on one side and away from it on the other. On a 300-page book, that drift compounds into a reader-visible asymmetry.

Inches to Millimeters: The Exact Conversions

KDP accepts both measurement systems in its metadata, but your PDF must be internally consistent. If you build in millimeters, build everything in millimeters. Mixed-unit documents are the second most common cause of preflight rejection after bad bleed.

The conversion constant is exact: 1 inch = 25.4 mm. No rounding. No "approximately."

Notice that 0.125" converts to 3.175 mm, not 3 mm and not 3.2 mm. If you round to 3 mm, you lose 0.175 mm per edge — across a 32-page signature that accumulates to 5.6 mm of cumulative drift at the fold, which is enough to push a full-bleed image visibly off-register. Set your document grid to 3.175 mm and leave it there.

No-Bleed vs. Bleed: Which Do You Actually Need?

Not every book requires bleed. Choosing correctly saves you setup time and eliminates an entire class of errors.

Here is the trap: bleed is a document-wide property, not a per-page property. If a single page in your 280-page book has a full-bleed image, the entire interior PDF must be built at the bleed canvas size — 6.125" × 9.250", not 6.000" × 9.000". The pages that do not use the bleed simply carry 0.125" of blank margin that gets trimmed away. You cannot mix page sizes inside one print-ready PDF.

Quick Verification: The Four-Number Check

Before you export, confirm these four values in your page setup dialog. If any one is off, stop and fix it.

1. Document width = trim width + 0.125" (e.g., 6.125" for a 6" book)
2. Document height = trim height + 0.250" (e.g., 9.250" for a 9" book)
3. Bleed setting in export = 0.125" on top, bottom, and outside; 0.000" on inside
4. Trim box / crop marks = positioned exactly 0.125" from top, 0.125" from bottom, 0.125" from outside, 0.000" from inside

Get those four right and your interior clears KDP's automated preflight on the first pass. Get them wrong and you will learn the same lesson every self-publisher learns eventually: the printer does not read your intentions. It reads your numbers.

3. How to Treat Photos, Background Tints, and Chapter Banners for Bleed

Bleed is not decoration. It is insurance against the trimmer's tolerance. On a 6" × 9" trade paperback, the trimmer cuts the bound book block to final size with a mechanical variance of roughly ±0.031" (1/32") on a well-maintained guillotine and up to ±0.062" on a worn one. If your artwork stops exactly at the trim line, a 1/16" drift leaves a sliver of unprinted paper — a white hairline — running down the edge of a full-bleed photo. That hairline is the single most common reason KDP rejects a print interior or, worse, ships a book with a visible defect. The fix is mechanical: push every edge-touching element 0.125" past the trim line and keep every piece of critical content 0.375" inside it.

The three concentric rectangles

Every page in a bleed-enabled interior is governed by three nested boundaries. Memorize these numbers for a 6" × 9" trim:

For a 300-page book with a 0.625" spine, the KDP interior PDF canvas is 6.25" × 9.25" (plus the gutter already baked into the margin math). The 0.125" bleed on the outside edges is where graphics go to die gracefully. The 0.375" safe zone is where they live.

Full-page photos

A full-page photo is not placed at 6" × 9". It is placed at 6.25" × 9.25" and positioned so its frame origin sits at −0.125", −0.125" relative to the trim box. In InDesign, that means the image frame's X and Y coordinates are negative. In Affinity Publisher, you drag the frame past the bleed guides until the red bleed edge is fully covered. In a LaTeX or HTML-to-PDF pipeline, you set the image to 100% of the page box and let the media box exceed the trim box by 0.125" on each side.

Two rules govern the image content itself:

• Resolution at bleed size. A 6.25" × 9.25" photo at 300 PPI requires 1,875 × 2,775 pixels. At 240 PPI (acceptable for uncoated offset, marginal for KDP's digital press) you need 1,500 × 2,220 pixels. If your source is 1,800 × 2,700 pixels, it is 288 PPI at 6.25" wide — fine. If it is 1,200 pixels wide, you are at 192 PPI and the halftone will look soft.
• Compositional safety. The 0.125" that gets cut is not visible. Do not place a subject's eyes, a product label, or a caption inside that band. Assume 0.125" of every edge is gone.

A facing-page spread complicates this. If you run a photo across two pages, the gutter side loses 0.125" to bleed plus the gutter allowance (typically 0.75"–0.875" of total margin for a 300-page book). The photo must be built as a single 12.5"-wide image, then split at the spine, with 0.125" of bleed on the outer left and outer right edges only. Never add bleed to the gutter side of a spread — the gutter is bound, not cut.

Chapter title banners and header bars

A chapter banner is a colored rectangle that bleeds off the top and one or both outer edges. The fill extends to the bleed line; the text inside it stays in the safe zone. Here is the geometry for a 6" × 9" page with a banner running across the top and down the outside edge:

The banner fill's width is 6.125", not 6.25", because only the outer edge bleeds — the gutter edge sits inside the binding and must not carry a fill that could clash with the facing page. If the banner runs across the full width and the book is a single-page chapter opener, the fill is 6.25" wide and the text block is centered within the 5.25" safe width.

Color choice matters here. A banner fill in a light tint — say 10% cyan, 5% magenta — will show a visible seam if the trim drifts, because the cut edge of a tint reads as a line against the white paper. A solid 100% ink or a rich black (60/40/40/100 CMYK) hides drift better. Avoid pure RGB values; convert every banner to CMYK and check that the total ink coverage stays under 300% for KDP's digital press.

Side navigation tabs (thumb indexes)

Thumb indexes — the stepped tabs on the outside edge of reference books, Bibles, and manuals — are the most bleed-sensitive element in the entire interior. Each tab is a small colored rectangle that bleeds off the outside edge, and each tab must be positioned so its visible portion is a consistent width after trimming.

For a 6" × 9" page with a 0.125" outside bleed, a tab that should read as 0.375" wide after trim is drawn as 0.500" wide, positioned at X = −0.125". The tab's top edge sits at a calculated Y so that consecutive tabs step down the page edge in a staircase. For a 12-tab index on a 9" page, with the tab band occupying 7.5" of vertical space, each tab is 0.625" tall with no gap, or 0.500" tall with a 0.125" gap.

Tab labels — the letter or word identifying each section — must sit inside the safe zone. If a tab's visible width is 0.375" and the label is set vertically, the label's baseline should be 0.125" from the tab's inner edge and no closer than 0.375" from the trim. In practice, most thumb-index labels are set at 7–8 pt, rotated 90°, and right-aligned to the tab's inner edge.

The 0.375" safe zone rule

The safe zone is not a suggestion. It is the boundary between "this will survive trimming" and "this might get clipped." A full-bleed photo can extend to the bleed line. The caption under it cannot. A banner fill can run to the bleed line. The chapter subtitle inside it cannot. A tab can bleed off the edge. Its label cannot.

Worked example. A chapter opener has a photo bleeding off the top and both outer edges, a banner overlay across the bottom of the photo, and a chapter title inside the banner. The photo frame is 6.25" × 5.25", positioned at X = −0.125", Y = −0.125". The banner is a 6.25" × 1.00" fill positioned at X = −0.125", Y = 4.125" (so its bottom edge is 5.125" from the top of the trim). The chapter title is a text block 5.25" wide, centered, with its first baseline at Y = 4.50" — which places the cap height at approximately 4.375" from the top, or 0.375" below the banner's top edge. Every critical element clears the safe zone. Every fill reaches the bleed. Nothing that matters is within 0.125" of the cut.

One final check before export. In Acrobat, open Print Production → Output Preview and toggle the "Trim" and "Bleed" boxes. Every photo, tint, and banner should extend past the trim box to the bleed box. Every text block should sit inside the trim box with at least 0.375" of clearance. If a caption touches the trim box, move it. If a banner stops short of the bleed box, extend it. The trimmer will not negotiate.

4. The Dreaded White Sliver Trap: Why 0.125" Trimming Variance Requires Overhang

You export your interior PDF. The image sits flush against the 6.000" × 9.000" trim box. On screen it looks perfect — edge-to-edge, no gap, exactly what you designed in Canva or InDesign. You upload to KDP. The automated preflight kicks back a rejection. The image "extends too close to the trim line." You measure again. It's dead on. So what went wrong?

Nothing is wrong with your measurement. Everything is wrong with your assumption about what trimming actually is.

The white sliver is the single most common cause of interior file rejection at KDP, and it is almost always an author's first hard lesson in prepress reality. The fix takes ninety seconds once you understand the geometry. The confusion, though, is real — and it's worth dissecting properly, because the same mistake reappears in spine text, full-bleed chapter openers, and cover wraps.

What a trimmer actually does to paper

A commercial perfect-bound trimmer is not a laser. It is a guillotine. KDP's print partners — typically Ingram or a regional offset facility — stack between 200 and 800 printed sheets into a "lift," clamp them hydraulically, and drive a hardened steel blade through the entire stack in one stroke.

The blade is sharp. The clamp is tight. The tolerance is still not zero. Industry-standard trim variance on a stacked guillotine runs ±0.0625" (±1/16"), and on a bad day with a dull blade or a misaligned back gauge, you can see ±0.125" (±1/8"). KDP's own documentation acknowledges this: it specifies a tolerance window and designs its preflight rules around the worst case, not the average.

Here is the part most authors never internalize. The blade does not move the paper. The blade removes it. Whatever falls outside the cut line is gone. Whatever sits inside the cut line remains — including any unprinted paper that was hiding there.

The math of a 0.050" miss

Let's put real numbers on the defect. A 6" × 9" trade paperback page holds roughly 54 square inches of trim area. A 0.050" sliver running the full 9" height occupies 0.45 square inches — about 0.83% of the page. That sounds trivial. It is not.

At the worst-case 0.125" shift, you lose more than a full square inch of image to white paper. On a photograph, a chart, or a color block, that is a visible failure. On a book with a $14.99 list price and a 60% wholesale discount, you are shipping a $6.00 net product that looks like a $6.00 product.

Why KDP preflight rejects the "almost bleed"

KDP's interior PDF validator enforces a binary rule. For any element that touches the trim line, you must satisfy one of two conditions:

1. Full white margin: The element stops at least 0.25" inside the trim line. No bleeding. No ambiguity. The trimmer can shift anywhere within tolerance and the element remains fully on the page with white space around it.
2. Full bleed extension: The element extends at least 0.125" past the trim line on every bleeding edge, into the bleed box. The trimmer removes the overhang, and the printed area survives to the cut edge regardless of shift direction.

There is no third option. There is no "0.06 inches is probably fine." The validator does not negotiate. It measures your content bounding box against the trim box and the bleed box, and if your image terminates between 0.000" and 0.125" past trim, it fails.

The "Almost Bleed" rejection, decoded

This is the number one confusion point. An author reads "add 0.125" bleed" and adds 0.125" to the page size — making the canvas 6.25" × 9.25" — but then places the image so it stops at the original 6.000" × 9.000" trim line. The image now sits 0.125" inside the enlarged canvas. The author believes they have added bleed. They have added canvas.

Bleed is not extra page. Bleed is extra image. The image must physically extend into that 0.125" zone. If the printed area stops at trim, the bleed zone is empty white paper, and the trimmer will cut somewhere within its tolerance — sometimes inside the image, sometimes outside, leaving the sliver.

Read that last line again. The image must cross the trim line. Not approach it. Not touch it. Cross it, with at least 0.125" of printed content on the far side.

The 0.25" white margin alternative

If you don't want to deal with bleed at all, pull every image and every colored element at least 0.25" inside the trim line. On a 6" × 9" page, that means your content box for bleeding elements is effectively 5.5" × 8.5". You lose half an inch of usable width and half an inch of height. For text-heavy books, this is fine — you were going to inset your text block anyway. For image-heavy books, it's a real constraint.

The 0.25" figure is not arbitrary. It is 2× the maximum trim variance. If the blade shifts 0.125" in the worst direction, a 0.25" margin still leaves 0.125" of white space between the image edge and the cut. The image survives intact. No sliver, because there was never any printed content near the cut line to begin with.

How to verify your file before upload

Open your PDF in Acrobat Pro or a prepress tool that displays trim and bleed boxes. Turn on the trim box overlay. Every image that touches a page edge should visibly cross the trim line by 0.125" or more. Every image that does not touch a page edge should sit 0.25" inside.

If you are working in Canva, Affinity Publisher, or Scribus, set the document size to the bleed-inclusive dimensions (6.25" × 9.25" for a 6" × 9" book) and place guides at the 0.125" inset to mark the trim line. Design to the guides. Export with bleed enabled.

If you are working in InDesign, set the document to 6" × 9" with 0.125" bleed on all sides. InDesign handles the math automatically. Just make sure your images extend to the bleed edge, not the trim edge.

The white sliver is preventable. It costs nothing to prevent. It costs a rejected upload, a re-export, and a lost afternoon to fix after the fact. Extend the image past the trim line by 0.125", or pull it back by 0.25". Those are the only two numbers that matter.

5. Step-by-Step Export Guide: Setting Bleed in InDesign, Word, and Automated Engines

Bleed is not a design preference. It is a mechanical requirement of the trimmer. When a guillotine blade descends on a 500-sheet lift of 60# cream stock, it does not slice on a perfect vector line. Paper shifts. The blade drifts by 1/64" to 1/32" across the lift. If your full-bleed image stops exactly at the 6.000" × 9.000" trim box, that drift exposes a 0.5–1.0 mm sliver of white paper along the edge. On a dark cover, that sliver looks like a printing defect. It is a printing defect — yours.

KDP's print specification is unambiguous: 0.125" (3.175 mm) of bleed on the top, bottom, and outside edges. The inside (gutter) edge gets 0", because that edge is bound, not trimmed. Get this wrong and your file fails preflight. Get it right and the trim variance becomes invisible.

Below are three workflows, ranked by reliability. Pick one. Do not mix them mid-project.

5.1 Adobe InDesign: The Reference Workflow

InDesign is the only desktop tool that models bleed as a first-class document property. The bleed box travels with the file into the PDF export without manual geometry hacks.

1. Create the document with the correct trim. File → New → Document. Width: 6 in, Height: 9 in. Pages: your total page count must be divisible by 2 for a print interior. Leave "Facing Pages" checked for interiors, unchecked for covers.
2. Set the bleed. In the New Document dialog, expand the Bleed and Slug section. Enter:
   • Top: 0.125 in
   • Bottom: 0.125 in
   • Outside: 0.125 in
   • Inside: 0 in
   The Inside field must be zero. A nonzero inside bleed inflates your page geometry and pushes content toward the binding, which KDP rejects during interior review.
3. Retrofit an existing file. File → Document Setup → Bleed and Slug. Enter the same four values. The red bleed guide appears 0.125" outside the black trim line on three sides.
4. Extend your art. Any image, background color, or rule that touches the trim edge must extend past the black line to the red bleed line. A common error: designers place a background rectangle exactly at the page edge. It must overshoot by 0.125". Use the Transform panel: set the rectangle's X to -0.125 in and width to 6.25 in.
5. Export. File → Export → Format: Adobe PDF (Print). In the Export dialog, select the preset [PDF/X-1a:2001] or [PDF/X-4]. KDP accepts both; PDF/X-1a is the conservative choice for offset-style RIPs.
6. Marks and Bleeds tab. Check Use Document Bleed Settings. Do not check Crop Marks, Registration Marks, or Color Bars — KDP's automated trimmer does not need them and they can confuse the preflight engine. Leave Offset at 0.0833 in.
7. Output tab. Color Conversion: Convert to Destination. Destination: U.S. Web Coated (SWOP) v2 for color interiors, or Gray Gamma 2.2 for black-and-white. Profile Inclusion Policy: Include Destination Profile.
8. Compression tab. Downsample color and grayscale images to 300 ppi above 300 ppi, using Bicubic Downsampling. Set JPEG quality to Maximum. Do not let InDesign downsample below 300 ppi — that is KDP's floor for photographic content.

5.2 Microsoft Word: The Manual Geometry Workaround

Word has no bleed model. There is no "Bleed" field, no TrimBox, no MediaBox concept. Word thinks in terms of a single paper size. To produce a bleed-ready PDF from Word, you must fake the bleed by enlarging the canvas and repositioning the content.

The math is simple. KDP trim is 6.000" × 9.000". Bleed is 0.125" on top, bottom, and outside. Therefore:

Step-by-step in Word:

1. Layout → Size → More Paper Sizes. Enter Width: 6.125", Height: 9.25". Apply to Whole document.
2. Layout → Margins → Custom Margins. Enter the values from the calculation card above. Word cannot mirror margins automatically with asymmetric bleed, so you must build two master templates: one for verso pages, one for recto pages. This is tedious but non-negotiable.
3. Place full-bleed images as anchored, floating objects. Insert → Pictures. Then Format → Wrap Text → Behind Text. Drag the image so its edge aligns with the physical paper edge, not the margin. Use the Position → More Layout Options dialog and set absolute horizontal position to 0" for a left-bleed image, or to 6.125" minus image width for a right-bleed image.
4. Add a 0.125" bleed extension to background colors. Insert a rectangle shape (Insert → Shapes → Rectangle), set its fill to your background color, remove the outline, and position it to cover the full 6.125" × 9.25" canvas. Send it Behind Text.
5. Export. File → Save As → PDF. In the PDF options, choose Standard (publishing online and printing). Under Options, check Document structure tags for accessibility (helps KDP's automated checks) and uncheck Bitmap text when fonts may not be embedded. Under PDF Options, ensure ISO 19005-1 compliant (PDF/A) is unchecked — PDF/A strips the transparency KDP's preflight expects.
6. Verify the output. Open the PDF in Acrobat. File → Properties → Description. The page size should read 6.125 × 9.25 in. If it reads 6.00 × 9.00, your custom paper size did not apply. Start over.

5.3 Automated Publishing Engines: The BooklierAi Pipeline

Manual bleed configuration fails at scale. A 40-title backlist with mixed trim sizes, some 5.5" × 8.5", some 6" × 9", some 7" × 10", cannot be managed by hand without errors. Automated engines solve this by treating bleed as a computed property, not a user input.

The BooklierAi pipeline works in five stages:

The critical difference is stage 4. A hand-exported InDesign file may or may not carry a correct BleedBox. An automated engine writes the BleedBox explicitly into the PDF dictionary. KDP's preflight reads that dictionary entry and confirms the geometry without guessing.

Consider the arithmetic for a 320-page 6" × 9" paperback on 60# cream stock. Spine width = 320 pages × 0.002252" per page = 0.7206". The cover canvas becomes:

An automated engine computes this in milliseconds from the page count. A human designer computes it once, gets it right, and then reuses the template on a book with a different page count and ships a cover with a spine that is 0.04" too narrow. That 0.04" error wraps the front cover art onto the spine and the book looks self-published.

The export step is where 80% of KDP rejections originate. Not the writing. Not the editing. The geometry. Treat the four bleed values — 0.125", 0.125", 0.125", 0" — as fixed constants in your production pipeline. Verify the TrimBox and BleedBox in Acrobat before you upload. Then upload once, and move on to the next book.
